Universal Tilting Rotary Table (00-900)

Universal Tilting Rotary Table (00-900)
Universal Tilting Rotary Table (00-900)
Product Code : A11
Product Description

Universal Tilting Rotary Table (00-900)

Tilting range 0-90 degrees from horizontal vertical position, It is high rigidity. Minimum Set-up time: It has two screws to lock setting. Low profile body for bigger capability. Worm is hardened and ground. The ratio is 90:1 The work table is graduated a ful 3 60 so that of the handle moves the table through 4 Micro collar is graduated in steps of 2' min. The tail stock & Dividing plates are optional. The sizes is same as the rotary table, please see page A2. For arc or index cutting at milling machine, Grinding machine or drill Machine...


Order No. & Dimensions

Special Accessories
This is an accurate designed table for milling, boring and other machine tools. This table allows indexing, facing and other work to be carried out rapidly with extreme precision. Tiliting range 90 degrees from horizontal vertical position, 1 rotation of handle equals 3 degrees, 5 minutes tilting reading. 10 Second Vernier Scale. Table Dia1 Minute Graduations. Fast Degrees: Dividing Notch Pin & 24 Holes in 15 Degrees Around that insures Rapid & Accurate Spacing. Minimum Set-Up time. Rugged Construction.
